FLAG0 Enable Jumper (JP1 and JP4)

In standard configuration,
switch. can be connected to the AD1836 audio codec by inserting
FLAG0
. can be connected to the CS8416 S/PDIF receiver by inserting
JP4 FLAG0
. See "AD1836 Control Selection Jumper (JP23)" on page 2-11
JP1
more information.

FLAG1 Enable Jumper (JP5)

In standard configuration,
as a select for the SPI port. The
push button switch or the signal on the expansion connector (
the jumper is removed, the SPI can no longer communicate with the
AD1852 device.

Sample Frequency Jumper (JP6)

The jumper selects the sample frequency for the AD1852 device.
JP6
Table 2-6 shows the valid frequency modes.
Table 2-6. Sample Frequencies
Jumper Location
None installed
3 and 4
1 and 2
1 and 2, 3 and 4
