Top View

8 DIMM Slots
Feature Description
Power Supply Dual 920W high-efficiency redundant power supplies (Platinum level, 94%)
M.2 slot Single PCIe 3.0 x2 M-Key NVMe
SuperDOM ports Disk-on-Module port allows for flash cards to be mounted directly on the motherboard
DIMM slots Dual in-line memory module (DIMM) slots
Processor Intel Xeon Scalable Processor
System fans 8-cm counter-rotating fans used to provide cooling for the system
Figure 1-4. System: Top View
System Features: Top
15
Chapter 1: Introduction
Power Supply Module(s)
1 M.2 Slot
2 SuperDOM Ports
Processor
3 System Fans
