Drive Carrier
The drives are mounted in drive carriers to simplify their installation and removal from the
chassis. These carriers also help promote proper airflow for the drive bays.
Figure 3-6. Removing Dummy Drive from Carrier
Installing a Hard Drive to the Hard Drive Carrier
1. Remove the screws securing the dummy drive to the carrier.
2. Remove the dummy drive from the carrier.
Warning: Except for short periods of time (swapping hard drives), do not operate the server
with the hard drives removed from the bays.
Chapter 3: Maintenance and Component Installation
Figure 3-5. Drive Carrier
1
51
Dummy Drive
1
