4
Drive Carrier
3. Install a new drive into the carrier with the printed circuit board side facing down so that
the mounting holes align with those in the carrier.
4. Secure the hard drive by tightening all six screws.
5. Replace the drive carrier into the chassis bay, making sure that the drive carrier handle
is completely closed.
Note: Your operating system must have RAID support to enable the hot-plug capability of
the drives.
Chapter 3: Maintenance and Component Installation
SATA
Hard Drive
Figure 3-7. Removing the Hard Drive
