1
Diagnostics
Chapter
1-60
Chapter
■
Error Class
0xD : STXPBS001 Specific
Class
Byte
0
Station status 0
1
Station status 0
2
Station status 0
3
Master Address
4
PNO Ident Number High
5
PNO Ident Number Low
6
ID Diagnostic Header
7
Diagnostic allocation (Slot0~7)
8
Diagnostic allocation (Slot8~15)
9
Diagnostic allocation (Slot16~23)
10
Diagnostic allocation (Slot24~31)
11
Diagnostic allocation (Slot32~39)
12
Reserved
13
14
15
Device Status Diagnostic Header
16
Status Type (0xA0:Manufacture-specific)
17
Slot Number
18
Status differentiation (0:No differentiation)
19
Status message
20
Reserved
■
ID Related Diagnostic
Byte
Bit 7
Bit 6
6
ID Diagnostic Header (0x45)
7
Slot 7
Slot 6
8
Slot 15
Slot 14
9
Slot 23
Slot 22
10
Slot 31
Slot 30
11
Reserved
RSTi Network Adapter Manual User Manual - January 2012
■
Error code
Item
Bit 5
Bit 4
Bit 3
Slot 5
Slot 4
Slot 3
Slot 13
Slot 12
Slot 11
Slot 21
Slot 20
Slot 19
Slot 29
Slot 28
Slot 27
1: Slot Parameter write
error
2: Read memory error
3: Write memory error
Description
PROFIBUS Standard
Diagnostic
Extended Diagnostic
(ID Related Diagnostic)
Extended Diagnostic
(Device Status)
Bit 2
Bit 1
Bit 0
STXPB
Slot 2
Slot 1
S001
Slot 10
Slot 9
Slot 8
Slot 18
Slot 17
Slot 16
Slot 26
Slot 25
Slot 24
Slot 32
GFK-2746
