Stop Monitoring
How to Stop Monitoring
IO Test
online only
Move to Process Image Tab
GFK-2746
1 Introduction
online only
Stop monitoring for the selected Project.
1. Select project to stop monitoring in Project window.
2. Use one of the following methods.
Menu
Toolbar
Shortcuts
3. As monitoring stops properly, icon of project and NA is changed accordingly.
Icon
Offline status
Communication is good.
It can change output value of IO Module and check input value.
1. Select Process Image Tab in Main window.
2. Select Network Adapter or IO Module to be tested in Project window.
Select Network Adapter: All values are displayed in Hex Format.
Select IO Module
Chapter Chapter
5-61
Online → Stop Monitoring
Shift + O
Description
5
