Main Window
5-20
■
Start Page Tab: Homepage Browsing
It is possible to configure 'Goto Online' link at Options
Note: In case you want to change Start Page, please contact GE Intelligent Platforms.
■
Image Tab: displays currently activated image and information
The Image tab displays currently activated image and information
Click image, then Properties
1. Selection NA from Project Window

Name: Displays the name defined by user and the NA address is displayed in
blue.

Description: Displays a brief explanation for the selected Network Adapter.

Total Power: Displays total power consumption of IO in the connected NA.

Total Size: Displays total size of IO and NA at current node
RSTi Network Adapter Manual User Manual -January 2012
Figure 49: IOGuidePro Home page
of the selected device to display onscreen.
→
Configuration.
