4.3.2 SPDIF Selection Jumper (JP2)

JP2 is used select the SPDIF input to the CS8414 Digital Audio Receiver. When
the jumper is configured for an optical connection the TOSLINK optical input
connector (P4) should be used. When the jumper is configured for a coax
connection the RCA input connector (P5) should be used.

Table 4-1: SPDIF Modes

Jumper
Location
1 & 2
2 & 3

4.3.3 MCLK Selection Jumper (JP3)

JP3 is used to select the MCLK source for the AD1836 and AD1852.

Table 4-2: MCLK Selection

Jumper
Location
1 & 2
2 & 3

4.3.4 FLAG0 Enable (JP4)

In standard configuration, FLAG1 is connected to the AD1836 and used as a
select for the SPI port. This jumper should be removed to use the push button
switch or the signal on the expansion connector (P10). Once this jumper is
removed the SPI can no longer communicate with the AD1836.

4.3.5 FLAG1 Enable (JP5)

In standard configuration, FLAG1 is connected to the AD1852 and used as a
select for the SPI port. This jumper should be removed to use the push button
switch or the signal on the expansion connector (P10). Once this jumper is
removed the SPI can no longer communicate with the AD1852.

4.3.6 Sample Frequency Jumper (JP6)

JP6 is used to select the sample frequency for the AD1852. Table 4-3 shows the
valid modes that may be used.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Mode
Optical (factory default)
Coax
MCLK Source
Audio Oscillator (12.288 MHz)
(factory default)
Derived clock from SPDIF
Stream
4-6
