4.5.3 External port and Host Processor Interface (P9, and P10)
Two MICTOR board-to-board connectors provide all of the DSP's External Port
signals. Contact AMP for information about mating connectors.
Part Description
38 Position MICTOR
4.5.4 JTAG (P12)
The JTAG header is the connecting point for a JTAG in-circuit emulator pod.
Note: Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When an emulator is connected to the JTAG header, the USB debug interface is
disabled.
WARNING: When using an emulator with the EZ-KIT Lite board,
follow the connection instructions provided with the emulator.
4.5.5 Link Ports (P13 and P14)
Each link port is connected to a 26-pin connector. Refer to
information about the link port connectors.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Manufacturer
Part Number
Shogyo
SJ-0359AM-5
SWITCHCRAFT
PJRAS2X2S01
SWITCHCRAFT
PJRAS4X2U01
TOSHIBA
TORX173
SWITCHCRAFT
PJRAN1X1U01
Radio Shack
L12-2397A
Monster Cable
BI100-1M
Monster Cable
ILS100-1M
Monster Cable
IDL100-1M
Manufacturer
Part Number
AMP
2-767004-2
EE-106
for more
4-15
