2.4.4 Set-up the EZ-KIT Lite Hardware

The EZ-KIT Lite Evaluation board contains ESD (electrostatic
discharge) sensitive devices.
accumulate on the human body and equipment and can
discharge without detection. Permanent damage may occur on
devices subjected to high energy discharges.
precautions are recommended to avoid performance degradation
or loss of functionality. Store used EZ-KIT Lite boards in the
protective shipping package.
The ADSP-21161N EZ-KIT Lite board is designed to run outside your personal
computer as a stand-alone unit. You do not have to open your computer case.
Use the following steps to connect the EZ-KIT Lite board:
1. Remove the EZ-KIT Lite board from the package. Be careful when
handling these boards to avoid the discharge of static electricity, which
may damage some components.
2. Figure 2-1
LEDs used in installation. Confirm that your board is set up in the default
configuration before continuing.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Electrostatic charges readily
Proper ESD
shows the default jumper settings, connector locations and
2-4
