Smart Charging Available for
configuration Eve download on the
Single Knowledge Base
Training for Alfen Trainings charging
charging stations stations equip-
ment

1.5 Copyright

Copyright ©2023 Alfen ICU B.V. All rights reserved. The
disclosure, duplication, distribution and editing of this
document, or utilization and communication of the content
are not permitted, unless authorized in writing by Alfen.
All rights, including rights created by a patent, grant or
registration of a utility model or a design, are reserved.
The English version of this manual is the original source
document. Manuals in other languages are translations of
this source document.
Eve Single is a trade mark by Alfen ICU B.V. Any
unauthorized use of the trade mark is therefore illegal.

1.6 Operating conditions

Operating temperature
Relative atmospheric humidity
Electrical safety class
Degree of protection (casing)
IK protection (mechanical impact)
NOTE
The operating temperature stated is under the following
conditions:
• A maximum charging power of 11 kW is guaranteed at
an ambient temperature above 40 °C and below the
stated maximum operating temperature.
• The influence of direct solar radiation on the charging
station is excluded.
• The influence of a front cover with another color than
RAL9016 is excluded.
• The influence of Customizations applied on the charging
station is excluded.
• The stated charging performance is solely applicable to
the charging station, actual performance is dependent
on the vehicle and the grid connection.
Alfen ICU B.V. | Installation Manual | Eve Single Pro-line & S-line | EV Charging Stations | V2.2 | EN | 04/2023 | 203130236-ICU
1. SAFETY AND USAGE INSTRUCTIONS

1.7 EU Declaration of Conformity

Document re-
quired for con- The Eve Single complies to the following directives:
figuring Smart •
Charging features. •
•
class-room train-
•
ings provided by
Alfen.
The EU declaration of conformity can be requested from
Alfen. Please refer to the contact data on the backpage of
this manual.
-25....+55 °C
5 - 95 %
Class I
IP55
IK10
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
Radio Equipment Directive 2014/53/EU
Harmonized standards: IEC 61851-1 ed. 3 (2017) -
Electric vehicle conductive charging system - General
requirements, on national level implemented under:
AT: ÖVE/EN 61851-1
BE: NBN EN 61851-1
DE: DIN-EN 61851-1
FIN: SFS-EN 61851-1
FR: NF-EN 61851-1
NL: NEN-EN-IEC 61851-1
NO: NEK-EN-61851-1
UK: BS-EN 61851-1
ETSI EN 300 330-2 V1.5.1 – NFC reader
EN 301 908-1 V11.1.1 / EN 301 908-13
V11.1.2 / EN 301 511 V12.5.1 - GPRS
NOTE
5
