Key Description - Furuno INMARSAT-C FELCOM 18 Operator's Manual

2.2.1

Key description

Key
Esc
F1 - F10
BackSpace
Ins
Del
Home
End
PgUp
PgDn
↑, ↓, ←, →
Enter
Shift
Alt
Spacebar
Caps Lock
Tab
Ctrl
NumLk
Note: In telex, lower case, #, &, *, $, @, %, etc. are not permitted. A full list of charac-
ters usable in telex appears in the Appendix. For e-mail all characters and symbols
may be used.
• Cancels key input and returns to previous display screen.
• Long push to return to the standby display.
Select menus. See section 2.2.3.
Deletes the character to the left of the cursor.
Works the same as "paste." See "How to cut and paste text" in
section 4.2.4.
Deletes the character selected with the cursor.
Moves the cursor to the top of the message being edited.
Moves the cursor to the bottom of the message being edited.
Goes to the previous page of the edit screen.
Goes to the next page of the edit screen.
Control the cursor.
Registers key input; inserts carriage return in TX message.
Selects upper or lower case alphabet. Press and hold down the key
and then press the [Caps Lock] key to get upper or lower case alpha-
bet. Note that only upper case alphabet are used in telex.
Provides the shortcut key operation when combined with an alphabet
key. See section 2.2.2.
Inserts a space. In addition, it displays the file list, a partial view of a
file, etc., depending on menu.
Turns upper case alphabet input on or off. The Caps Lock LED lights
when upper case alphabet input is on.
Inserts horizontal tab characters. The number of tab characters the
key can insert per line of text can be programmed for two, four or eight
tabs.
Works in combination with alphabet keys as follows:
• Ctrl + [M]: Same as Enter.
• Ctrl + [H]: Same as Back Space.
• Ctrl + [I]: Same as Insert.
• Ctrl + [V]: Same as Overwrite+Insert on Edit Mode in the Editor Set-
up menu.
Turns numeric input on or off. Note that you cannot enter alphabet
when the NumLk LED is lit.
2. OPERATIONAL OVERVIEW
Function
2-3
