How To Add Egc Channels - Furuno INMARSAT-C FELCOM 18 Operator's Manual

3.4.3

How to add EGC channels

The EGC Channel List stores EGC channels. There are currently four EGC channels,
one for each satellite. These four channels are pre-programmed into the unit and
marked in the [EGC Channel List] with asterisks. When more EGC channels become
available you can add them to the list as below.
1. Press the F8, 8 and 3 keys to show the [EGC Channel List].
2. Use the arrow keys to put the cursor where there is no data entered. Current EGC
channels are marked with an asterisk. These channels cannot be changed.
3. Press the Enter key to open the EGC channel list entry screen.
4. Enter EGC channel frequency code then press the Enter key. The EGC channel
frequency code range is 6000-14000.
5. Press the Esc key to open the [Update] window.
6. [Yes] is selected; press the Enter key.
Note: If the EGC channel frequency code entered is invalid, the message "Input
Error: Channel No." appears. Clear the error message by pressing the Esc key.
Put the cursor at the invalid frequency, press the Enter key then enter correct fre-
quency code.
7. Long-press the Esc key to return to the standby display.
EGC Channel List
ENTER: Set ESC: Quit
11080* 12580* 10840*
3. SYSTEM INITIALIZATION
11088*
3-13
