Complete Set Name Antenna Unit Communication Unit Terminal Unit Telephone Junction Box Telex Distress Alert Button Telephone Distress Button Spare Parts Installation Materials (Selection) Installation Materials (Selection) 11 AD Converter Type Code No. Mass (kg) IB-181 IB-281 IB-581 FC755D1 IB-312 IB-350 IB-360 SP16-01000...
Page 9
Optional Equipment Name Facsimile PFX-50 Received Call Unit IC-301 Telephone FC755D1 Modular Jack Box OP16-10 Modular Jack Box OP16-11 Modular Jack Box OP16-13 AC/DC Power PR-300 Supply Unit MCT-1540-55 Card Reader MCT-1540-81 5-pair cable 10m CO-SPEVV-SB-C 0.2 × 5P 10 5-pair cable 20m 11 5-pair cable 30m 12 5-pair cable 40m 13 5-pair cable 50m...
Page 35
For installation on a steel table, fix the telephone with nuts and bolts. For bulkhead mounting, use the bulkhead mounting base (supplied with telephone accessories). Select a location where temperature and humidity are moderate and stable. Secure sufficient space around the unit for ease of operation and maintenance.
2.10 Checking the Installation General Before turning on the system, check for proper installation, following the procedure shown below. Standard Equipment Communication Are all connectors firmly fastened? unit Is the copper strap firmly fastened? Junction boxes Are all connections on the terminal board correctly made? IB-312 Are all cables properly grounded by cable clamp? Is the unit properly grounded?
DC IN Figure 8 AC-DC power supply unit PR-300, rear view Connect a ground wire between ship's superstructure and a ficing screw on the PR-300. Output 10 A FURUNO PR-300 Fuse for ship's mains DC power sourse switch DC OUT...
4.4 Card Reader Card Reader The card reader useable with the FELCOM 81 is the Configuration MCT-1540-81 (Code No. 000-043-335). Extension cable and modem are optionally available. The card reader without installation materials is also avail- able (Type MCT-1540, Code No. 000-043-333). Name Main Unit MCT-1540...
Page 50
4.4 Card Reader Connection of Card Reader FELCOM81 Communication ・ The card reader should be installed nearest the most frequently used telephone. ・ The card reader connects to the communications unit (IB-281) of the FELCOM 81 with two connection cables (supplied) whose total length is 6.5 meters.
Page 51
Setting up Tele- phones/Fac- similes Set up telephones and facsimiles according to call appli- cation desired. Application 1. Non-credit card call only: 2. Credit card call/non-credit card call: 3. Credit card call: Preset 1. Pick up receiver of No.1 telephone. 2.
4.5 DGPS 4.5 DGPS An L-band DGPS receiver may be connected. This requires a connector fixing plate for DGPS. CP16-01602 (Code No.: 004-442-900) Name Connector fixng plate PH5P-L200-SMP2P Cable assy PH2P-L300-SMR2P Pan head screw 1. Turn off the communication unit. 2.
5.2 Setting of Telephone FC622SLIWG FC755D1 Change dialing format from dial to pushbutton as follows. (The handset should be hung in the hanger.) 1. Press the key. 2. Press the key. 3. Press the key to display "Pb." 4. Press the key again.
5.4 Attaching the Compass Safe Distance and Inmarsat B Seals 5.4 Attaching the Compass Safe Distance and Inmarsat B Seals Attach the compass safe distance seals (supplied with installation materials) for the units shown below. When the same units (for example: telephone, facsimile, etc.) are used for other than FELCOM 81, attach ""seals b to them to distinguish.
5.5 Facsimile PFX-50 Setting Turn on the power while dialing [*], [1], [3] to initialize the PFX-50's memory. Change the dial mode to "push button" with the MODE switch. (Choose position "T". ) 5.5 Facsimile PFX-50 Setting Dial Mode MODE Switch Chosse "T".
5.6 Personal Computer Connection 5.6 Personal Computer Connection Booting up by disk drive Booting up by hard disk drive You can use a personal computer as the terminal unit for the FELCOM81, by installing the contents of a program disk on the PC. Note: Basic knowledge of DOS commands is required.
6.1 Setting Up Overview Set up the terminal unit, editor screen and communication unit (Class 2). When there is no navigation input or gyro input, enter them manually referring to operator's manual. Turn on the Main Unit and Terminal Unit. After a while, the Main Menu, shown below, appears.
6.2 Registering Answerback Code (Class 1 only) 6.2 Registering Answerback Code Overview Procedure Enter ship's answerback code at installation. The answerback code cannot be changed once registered. Confirm the code before pressing key. Enter Press display. Cursor !! ATTENTION: CAN NOT REENTER !! Enter your ship's answerback code given by Inmarsat, then press the [Normally, answerback code consists of telex IMN...
