6. DATA REPORT AND POLLING
6.3

DNID (Data Network Identification)

When you make a contract with an information provider, DNIDs are downloaded from
the information provider to the FELCOM, via the appropriate LES.
Up to 64 DNIDs can be downloaded to the FELCOM. You can see which DNIDs are
stored by following the procedure shown below.
6.3.1

How to display DNIDs

You need to make a contract with an LES to exchange data within a group. The LES
sends a DNID (Data Network Identification) number to each member of the group. The
FELCOM can store a maximum of 64 DNIDs.
Press the F5 and 4 keys to show the [Data Network ID] list.
Mark '*' means activation.
No.
01
02
03
04
05
06
07
08
"Act" indications and their meanings
Asterisk: Enabled DNID
No indication means disabled DNID.
24h: Enabled DNID. TX cycle changes every 24 hours.
STP: Enabled DNID. TX temporarily disabled.
6.3.2

How to enable, disable DNIDs

Note: The [Disable], [Enable (24-hour)] and [Enable (Temporary Stop)] settings
are for LRIT only. Only use these settings with a DNID for LRIT.
1) When anchored or docked, the [Enable (24-hour)] and [Enable (Temporary Stop)]
settings can be used to temporarily stop of send 24-hour interval reports.
2) When the setting is changed from [Enable (24-hour)] or [Enable (Temporary Stop)]
to [Enable], reports are sent at 6-hour intervals again. Where DNID is set to a DNID
other than for LRIT and [Enable (24-hour)] or [Enable (Temporary Stop)] is select-
ed, change the setting to [Enable] then ask the administrator for a compatible
DNID for LRIT and request a polling command from the land station.
3) The interval reports can be stopped by selecting [Disable]. Interval reports will not
be sent after reverting the setting to [Enable]. To reinstate the interval reports,
change the setting to [Enable] then ask the administrator for a compatible DNID for
LRIT and request a polling command from the land station. Where the DNID is not
compatible with LRIT, follow the procedure mentioned above, even when selecting
[Disable].
6-8
Sub address
Data Network ID
Act DNID LES Subaddr
* 01000 002 000
24h 01001 001 001
STP 01002 102 002
01003 131 003
* 01004 202 004
24h 01005 210 000
STP 01006 302 001
01007 304 002
Member number using DNID
Ctrl+P: Print
Member Text
235
085
215
033
227
013
079
089
