3.11 Cable Routing Diagram

Refer to the diagram below for a representation of how the main cables are routed throughout
the system. When disconnecting cables to add or replace components, refer to this diagram
when adding or replacing components so you can reroute them in the same manner. Proper
cable routing is important in maintaining proper airflow through the system.
CBL-PWEX-1238
CBL-SAST-1245LP-85
CBL-SAST-1242LP-85
CBL-SAST-1294LP-85
CBL-SAST-1201LP-85
CBL-CDAT-0795-1
Chapter 3: Maintenance and Component Installation
CBL-OTHR-1115
CBL-SAST-1202LP-85
CBL-PWEX-1237
CBL-SAST-1227LP-100
VGA Cable
Intrusion Cable
Figure 3-21. Cable Routing Diagram
69
USB3.0 Cable
