3.2 Accessing the System

The system is comprised of two trays, a CPU tray and a carrier board tray. Each tray can
be removed from the chassis using releasing levers or handles. Before removing the trays,
power down the system, as described in
It is recommended that you should NOT remove the carrier board tray unless necessary. For
more details on removing the carrier board tray, see
Chapter 3: Maintenance and Component Installation
Section
Figure 3-1. Carrier Board Tray and CPU Tray
3.1.
3.6 Carrier Board
29
Tray.
Carrier Board Tray
CPU Tray
