3.7 Storage Drives

A total of four NVMe/SATA/SAS hybrid drives may be housed in the CSE-428G2 chassis. All
four drive bays are hybrid.
The drives are mounted in drive carriers to simplify their installation and removal from the
chassis. (Both procedures may be done without removing power from the system.) These
carriers also help promote proper airflow.
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and
servers. For information on recommended HDDs, visit the Supermicro website at
supermicro.com/products/nfo/storage.cfm

Drive Carrier Indicators

Each drive carrier has two LED indicators: an activity indicator and a status indicator. In
RAID configurations, the status indicator lights to indicate the status of the drive. In non-RAID
configurations, the status indicator remains off. See the table below for details.
LED Color
Blue
Activity LED
Blue
Red
Red
Red
Status LED
Red
Red
Red
Green
Chapter 3: Maintenance and Component Installation
Hard Drive Carrier LED Indicators
State Status
Solid On SAS/NVMe drive installed
Blinking I/O activity
Solid On Failed drive for SAS/SATA/NVMe
Blinking at 1 Hz Rebuild drive for SAS/SATA/NVMe
Blinking with two
blinks and one stop Hot spare for SAS/SATA/NVMe
at 1 Hz
On for five seconds,
Power on SAS/SATA/NVMe
then off
Blinking at 4 Hz Identity drive for SAS/SATA/NVMe
Solid On Safe to remove NVMe device
Blinking at 1 Hz Attention state- do not remove NVMe device
