Replacing Gaudi OAM Modules

Individual Gaudi OAM modules and carrier board are recommended to be serviced by
Supermicro due to the optimized density of the system. However, when there's a need, follow
the steps below.
Replacing a Gaudi OAM Module
1. It is recommended that you go to the BMC dashboard and select the GPU tab to locate
any failed Gaudi OAM modules. Normally, information on all eight Gaudi OAM modules
should be displayed. Fields of any failed modules remain blank. For details on accessing
the remote console, refer to
Figure 3-6. Locating the Failed Carrier Board Module
Chapter 3: Maintenance and Component Installation
Baseboard Management Controller User's
50
Manual.
