Chapter 2. TECHNICAL SPECIFICATION
2.1. MAxx/HP² front view
Figure 2. MA32/HP² front view
Table 1. DEVICE ELEMENTS FRONT
NR DESRIPTION
POWER SWITCH
POWER LED
DISPLAY
BUTTONS
VENTILATION GRILLS
2.2. MAxx/HP² back view
2023-01-05 | Rev. 3.17.0
Chapter 2. TECHNICAL SPECIFICATION
2.1. MAxx/HP² front view
NOTE
Hard disconnect Mains
POWER LED
DISPLAY / BUTTONS
DISPLAY / BUTTONS
Magnetically attached see:
2.1. MAxx/HP² front view | 5/86
MAXX/HP²
SERVICE
