6.8.5. HOUSING
FAN MODE NORMAL is the recommended mode to keep all components as cool as
possible to improve lifetime. When not much output power is required, the FAN MODE
could be changed to SILENT or PASSIVE (LP² only) which will use different fan speeds to
reduce noise.
MODE
NORMAL
SILENT
PASSIVE (LP² only)
6.8.6. VOLTAGE REFERENCE
VOLTAGE REFERENCE defines the maximal output peak-voltage when feeding an 0dBFS
signal on any input interface. Due to different maximum rail voltages based on the
hardware device, a clipping could occur.
This is intended to match the gain of different amplifiers to output the same voltage
with a given digital input signal.
6.8.7. DEVICE MUTE
En-/disable mute on startup, if enabled, the MASTER MUTE will be set on every start up.
An additional VOLUME RAMP can be enabled, which will linearly increase the dB value
until it is reached its desired value after EVERY MASTER MUTE unmute.
2023-01-05 | Rev. 3.17.0
CPU FAN
100%
Temperature controlled
OFF, but Temperature
controlled if exceeds
HOUSING FAN
100%
Temperature controlled
OFF, but Temperature
controlled if exceeds
MAXX/HP²
Chapter 6. WEBSITE
6.8. DEVICE
PSU FAN
Temperature & Load
controlled
Temperature & Load
controlled
not present
6.8. DEVICE | 69/86
