2.4. CONNECTIONS & CABLE
Control input connectors
Audio signal input connectors
Speaker connector
AC mains

2.4.1. MAINS SUPPLY

Power supply
Operating Voltage
AC Current typ.
Inrush Current
Suggested circuit
breaker
Earth Leakage
Current
Power Factor
amps power off
idle
1/8 power @ 4 Ohm
Consumption /
current draw
amps power off
idle
1/8 power @ 4 Ohm
Power Factor
amps power off
idle
1/8 power @ 4 Ohm
Consumption /
current draw
2023-01-05 | Rev. 3.17.0
RJ45 ( 100Mbit/s Ethernet )
RJ45 ( DANTE ), BNC 75R ( MADI Coax, AES3id ), SC Optic ( MADI Fibre )
Wuerth Elektronik 691352710002
Phoenix Contact MSTB 2,5/ 2-ST - 1754449
C19
Two Universal, regulated switch mode with PFC (Power Factor Correction)
90 - 264VAC 50/60Hz
<0.75mA / 240V
32 CH Version
@230V
0.46
0.64
0.96
@230V
36W
98W
1514W
24 CH Version
@230V
0.44
0.58
0.94
@230V
Chapter 2. TECHNICAL SPECIFICATION
2.4. CONNECTIONS & CABLE
14.3A per PSU
60A max.
2x B16
@110V
0.85
0.95
0.98
@110V
36W
102W
1532W
@110V
0.83
0.93
0.99
@110V
