Figure 41. MAXX/HP² filter cleaning / replacement
Please clean the filter when dirty. Depending on the installation environment, a regular
check is highly recommended.
Remove the grill
by gently pulling on it, it is attached with magnets, no tools required.
Clean the filter
with compressed air and put it back together.
9.4. SPARE PARTS
Table 12. SPARE PARTS
INNOSONIX PART
DESRIPTION
NUMBER
12578
2-Pol Speaker Connector
13403
air filter foam
13115
fan grill
13356
power cord C19 Typ E/F 2m (IEC-LOCK C13 to 3-pin Schuko CEE
7/7)
2023-01-05 | Rev. 3.17.0
MAXX/HP²
Chapter 9. SERVICE
9.4. SPARE PARTS
REFERENCE
CONNECTIONS & CABLE
FILTER CLEANING
FILTER CLEANING
AVAILABLE POWER
CORDS
9.4. SPARE PARTS | 81/86
