Chapter 5. Frontpannel

5.1. DISPLAY / BUTTONS

5.1.1. DISPLAY MENU

Figure 14. MENU STRUCTURE
Table 4. MENU PAGES
NR
DESCRIPTION
Overview Page with Hostname, IP and Channel Status (see. OVERVIEW)
Status Page with Temperatures and PSU Load and Fan Speeds
Info Page with Model, Serial, Software Version and Software Options
Network Settings Page to change IP type and address
2023-01-05 | Rev. 3.17.0
MAXX/HP²
Chapter 5. Frontpannel
5.1. DISPLAY / BUTTONS
5.1. DISPLAY / BUTTONS | 24/86
