6.6.13. SPEAKER SETTINGS

SINGLE EDIT
Figure 31. SPEAKER SINGLE CHANNEL EDIT VIEW
NR DESCRIPTION
Metadata of the active speaker preset.
Remove the speaker preset.
Download the speaker preset file to share it or apply to others channels.
Load a speaker preset file from your computer.
Create a speaker preset from channel dsp data
Load the speaker preset dsp data to the channel dsp
Enable/Disable speaker detection.
Set detection threshold and debounce. The 20 kHz current value has to be lower than the threshold for
"debounce" seconds to trigger an error.
Set 20 kHz pilot tone generator level in dBFS which will be added to the actual output signal of the amplifier.
Shows measured current at 20 kHz (yellow line indicates threshold)
Shows actual speaker detection status.
2023-01-05 | Rev. 3.17.0
WEBPAGE SPEAKER PRESET CREATE.
WEBPAGE SPEAKER PRESET
6.6. CHANNEL SETTINGS | 56/86
MAXX/HP²
Chapter 6. WEBSITE
6.6. CHANNEL SETTINGS
LOAD.
