2.5. AMP OUTPUT

To connect speakers, use 2-Pol Terminal Blocks.
Output Power (EIA J Test
Standard 1kHz 1% THD)
Max output Voltage
Max output Current Limited
Emergency Shutdown Current
DC Offset
Frequency response
S/N typ
Analog Gain
THD+N @ 4Ω
SMPTE IMD
CCIF IMD
Output impedance
Crosstalk
Latency @48kHz
Protection
2023-01-05 | Rev. 3.17.0
4Ω
280W
52 V
10Hz-20kHz / 4-8Ω: +0.5 -0.5dB
Software Adjustable, 0dBFS on any Input Interface ⇒ 20V
1W 10W
< 0.05% < 0.05%
channel enabled
typ < 75dB typ 90dB (distant
channels)
Overtemperature, DC and Overcurrent
Chapter 2. TECHNICAL SPECIFICATION
8Ω
140W
peak
20 A
peak
31 A
peak
<25mV
105dBA
p
280W
1%
< 0.1% @ 1/8 Power 4Ω
< 0.1% @ 1/8 Power 4Ω
typ 10 mΩ
channel disabled
typ < 100dB
1.1ms
2.5. AMP OUTPUT | 15/86
MAXX/HP²
2.5. AMP OUTPUT
8Ω Bridge-Mode
500W
104 V
peak
- 60V (default: 60V )
p p
300W
2%
