  • Page 1 7KT PAC1200 <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch <documentclass> z.B. Gerätehandbuch System Manual <documentclass> z.B. Gerätehandbuch Systemhandbuch 版本 Издание Wydanie Yayım Edizione Edição Edition Edition Ausgabe 11/2016 Edición siemens.com/lowvoltage...
  • Page 3 ___________________ Introduction ___________________ Safety notes ___________________ Product description ___________________ Connection Measuring Devices 7KT PAC1200 multichannel current ___________________ measuring system Operator control (software) ___________________ Service and maintenance System Manual ___________________ Technical data ___________________ Appendix ___________________ ESD guidelines 11/2016 2514374103-02...
  • Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 5: Table Of Contents

    Table of contents Introduction ..............................7 Introduction ..........................7 Safety notes ............................... 9 Safety instructions ........................9 Product description ..........................13 Products of the system ......................13 Functions ..........................15 Application area ........................20 Diagnostics options ......................... 21 System environment ....................... 22 Connection ..............................
  • Page 6 Table of contents Service and maintenance ........................55 Error messages ........................55 Disposal ..........................55 Technical data ............................57 Dimension drawings ....................... 60 7.1.1 Dimensions of the Data Manager ..................60 7.1.2 Dimensions of the sensor bar ....................61 7.1.3 Dimensions of the sensors on the sensor bar ...............

  • Page 7: Introduction

    Introduction Introduction The component parts of the 7KT PAC1200 multichannel current measuring system are described in this document ● Data Manager ● Sensor bar ● Sensors The configuration is also described via the web server. Target group The tasks described in this document must only be carried out by persons with the following electrical training/qualifications: ●...

  • Page 9: Safety Notes

    Safety notes Safety instructions The safety instructions that have to be followed when using the 7KT PAC1200 multichannel current measuring system are given below. DANGER Hazardous voltage. Will cause death or serious injury. Turn off and lock out all power supplying this device before working on it. Installation and maintenance work on this device must by carried out by authorized persons with the appropriate electrical training only.
  • Page 10 Safety notes 2.1 Safety instructions NOTICE Damage to, or destruction of, the Data Manager. Material damage. Do not connect an ISDN cable to the Data Manager’s network connection. Use the multichannel current measuring system in dry environments only and keep away from liquids.
  • Page 11 For safety reasons, changes to the sensor bar are forbidden unless expressly approved for the product by Siemens AG. Any use of the product other than the intended use described is considered improper use. Impermissible modification, conversions, repairs, or opening of the product are forbidden.

  • Page 13: Product Description

    Product description Products of the system ① Mobile terminal device ② Web browser ③ powermanager ④ Power distribution ⑤ Device for which current is being monitored The 7KT PAC1200 multichannel current measuring system is part of the energy management portfolio. The system comprises several components that are described in this chapter: ●...
  • Page 14 Product description 3.1 Products of the system Highlights ● Fully integrated smart meter ● 3-phase active power and reactive power energy measurement ● Measurement of energy as balancing counter ● Direct connection up to 63 A ● Optional use with external measuring transformer for extending the measuring range (e.g. 100 ...

  • Page 15: Functions

    Product description 3.2 Functions Data Manager The Data Manager is a measuring instrument that determines electrical measured values at the connection point and makes them available via LAN or RS485. The data collected by the Data Manager about power generation in your plant can differ from the data of the main energy counter.
  • Page 16 Product description 3.2 Functions Data Manager The Data Manager is a measuring instrument that determines electrical measured values at the connection point and makes them available via LAN. ① ⑧ Input N* Status LED ② ⑨ Input L3 Output L1 ③...
  • Page 17 Product description 3.2 Functions On the left, you see 3 LEDs (Status, Network and Sensor) that indicate the status of the Data Manager. Under the LEDs is the Reset button that causes restart or resetting of the device. The accuracy of current measurement by the current sensors is ±1 % of the full-scale value, and the accuracy of the voltage measurement of the Data Manager is ±0.5 % of the full- scale value.
  • Page 18 Product description 3.2 Functions Sensor bar Currents in AC power systems can be measured with the sensor bar. The measured data are forwarded to the Data Manager via the RS485 bus and evaluated. The Data Manager also supplies the 9 V to the sensor bar. The sensor bar is offered in four variants, with three, six, nine or twelve slots respectively for the current sensors.
  • Page 19 Product description 3.2 Functions Sensor ① Securing mechanism for connecting the individual sensors in the sensor bar ② Cable entry for the power cable ③ Connections for the sensor bar 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 20: Application Area

    Product description 3.3 Application area Application area The system is used primarily in the following areas: ● Small businesses ● Halls ● Residential buildings ● Supermarkets ● Data centers ● Office buildings Application example of a brewery Figure 3-1 Application example 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 21: Diagnostics Options

    Product description 3.4 Diagnostics options Diagnostics options Status indication via LEDs of the Data Manager ① Table 3- 1 Status: Indicates readiness Status Readiness for operation Device switched off Orange Voltage boot active Green, slow flashing Linux is booting Green, rapid flashing Firmware update in progress Green, continuous Device ON...

  • Page 22: System Environment

    The Data Manager is connected by LAN (if necessary via an additional router) to the PC running the Siemens-specific Sentron software. In communication via LAN, the Data Manager is the Modbus / TCP slave, while the PC with the Sentron software is the Modbus / TCP master. The data are sent continuously to the higher-level management system while a connection is present.

  • Page 23: Connection

    Connection TN system ① Line connection/ infeed ② Loads IT system ① Line connection/ infeed ② Loads 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 24: Cables

    Connection 4.1 Cables Transformer Overall connection Cables Power supply The Data Manager is supplied with energy via phase L1, in other words, the phase must always be connected. The Data Manager has a 63 A direct connection. For applications with other requirements, external current transformers can be additionally connected to the Data Manager.
  • Page 25 Connection 4.1 Cables Connections Above, you will find the connections L1, L2, L3; below also, plus an additional connection for N. In the middle, you will find the connection for the LAN cable. The connection for the RS485 connector is at the top of the Data Manager. Note: if the communication cable is incorrectly connected, the Data Manager switches to a protection mode and does not perform any measurements.

  • Page 27: Operator Control (Software)

    Operator control (software) Browser-based web application 5.1.1 System environment The web interface is designed for use on browser-based terminal devices (PC and notebook). Smartphone and tablet access to the web interface are also possible via WLAN. The web interface is optimized for a resolution of 1024x768 (WxH). The following minimum versions of the commercially available web browsers are supported: ●...

  • Page 28: Function Overview

    Operator control (software) 5.1 Browser-based web application Required settings for commissioning ● Time of day ● Language ● Network Settings ● Country ● Currency ● Tariff settings ● Budget ● Where applicable: Transformer ratio ● Modbus settings and sensor management (connection, labeling, phase assignment, and grouping of the individual sensors).

  • Page 29: Home Page

    Operator control (software) 5.1 Browser-based web application 5.1.3 Home page The web interface is called up by entering the IP address in the address line of the browser. The following page opens: Figure 5-1 Home The Start page shows the instantaneous consumption at the specified rate on the day. Depending on the configuration, consumption can be displayed per hour, per day, per week, per month, and per year.

  • Page 30: Statistics

    Operator control (software) 5.1 Browser-based web application 5.1.4 Statistics The statistics show the overall consumption of the selected sensors. Consumption can be shown both in euros and in kWh. The results can be displayed in the form of a pie chart or a bar chart, depending on selection. The periods that can be selected are as follows: ●...

  • Page 31: Current Values

    Operator control (software) 5.1 Browser-based web application 5.1.5 Current values Under the navigation item "Current values" you can see how high the consumption is at a particular moment in time. The "Current” value indicates this consumption. "Min / Max" indicates the minimum and maximum consumption. The kW values consumed at a certain time are shown in a curve diagram.

  • Page 32: Installment

    Operator control (software) 5.1 Browser-based web application 5.1.6 Installment The installment is calculated from the specified budget over a specified time period and from the monthly base fee. If the budget is exceeded, the final amount appears against a red background and a warning is issued on the Home page.
  • Page 33 Operator control (software) 5.1 Browser-based web application Figure 5-5 Installment - Year 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 34: Energy Stopwatch

    Operator control (software) 5.1 Browser-based web application 5.1.7 Energy stopwatch Consumption over a specific period can be checked with the current stopwatch. These measurements can be saved for comparison purposes. Figure 5-6 Energy stopwatch 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 35: Settings

    Operator control (software) 5.1 Browser-based web application 5.1.8 Settings 5.1.8.1 Start On the Settings homepage, you will find an overview of the serial number, firmware version, and LAN MAC address of the device. Figure 5-7 Settings - Start page 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 36: Device

    Operator control (software) 5.1 Browser-based web application 5.1.8.2 Device In the menu item Device Settings, the following settings can be made: ● Language ● Location ● Date ● Time of day ● Transformer ratio ● Password These settings appear on initial commissioning of the Data Manager. Figure 5-8 Device settings 5.1.8.3...
  • Page 37 Operator control (software) 5.1 Browser-based web application Sensor settings In the Sensor settings, you can search for sensor bars connected to the Data Manager by clicking the button "Rescan sensor bus". As soon as the sensor bars are detected, they appear in the left-hand column. The number of sensor bars is detected automatically.
  • Page 38 Operator control (software) 5.1 Browser-based web application Current values Under "Current values", the following live values of the sensors can be read out: ● Current ● Voltage ● Power factors of the different phases ● Current values of the individual sensors "0"...

  • Page 39: Network Settings

    Operator control (software) 5.1 Browser-based web application Note Note the ID number on the sensor bar. 5.1.8.4 Network Settings In the Network Settings, a static IP address can be assigned manually. The Data Manager is supplied with a fixed IP address (192.168.1.200). The Data Manager can also be assigned an individual name here.

  • Page 40: Data Export

    Operator control (software) 5.1 Browser-based web application 5.1.8.5 Data export Data transfer is configured via the Modbus settings. All measured values are transferred through this connection. As a bidirectional counter, the Data Manager measures active power [W], reactive power [var], apparent power [VA] and power factor per phase and in total, current [A] and voltage [V] per phase, and the network frequency [Hz].
  • Page 41 Operator control (software) 5.1 Browser-based web application Figure 5-11 Data export 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...
  • Page 42 Operator control (software) 5.1 Browser-based web application Data export with counter statuses and instantaneous values As well as the data export described above, there is the option of exporting a CSV file with the meter statuses and instantaneous values. This export variant is automated, in other words, data are exported, saved and sent by email, or stored on an FTP server over a specified period.

  • Page 43: Firmware Update

    Before this can take place, a data backup must be carried out. The firmware update can then be installed. The Data Manager restarts automatically following installation, and changes to the Start page. Firmware updates can be found in Industry Online Support (https://support.industry.siemens.com/cs/ww/en/ps/21681). See also Firmware Update (https://support.industry.siemens.com/cs/ww/en/ps/21681) 5.1.8.7...
  • Page 44 Operator control (software) 5.1 Browser-based web application Figure 5-13 Tariff settings Adjust tariff Under "Adjust tariff", the tariff can be changed at a particular time. 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 45: Budget Settings

    Operator control (software) 5.1 Browser-based web application 5.1.8.8 Budget settings Two values can be entered for budget settings: ● Available budget ● Period during which the budget is to be used When calculating the installment, the budget is distributed evenly across the number of months.

  • Page 46: Application For Mobile Devices

    To use the application for mobile devices, it must first be installed on the desired devices. The procedure depends on the device used. Android device Download the application from Google Play Store (https://play.google.com/store/apps/details?id=de.siemens.homebox&utm_source=global_co &utm_medium=prtnr&utm_content=Mar2515&utm_campaign=PartBadge&pcampaignid=MK T-Other-global-all-co-prtnr-py-PartBadge-Mar2515-1). iOS device Download the application from Apple iTunes (https://geo.itunes.apple.com/us/app/7kt-...
  • Page 47 Operator control (software) 5.2 Application for mobile devices The system to be monitored can now be selected from this list. See also Android link (https://play.google.com/store/apps/details?id=de.siemens.homebox&utm_source=global_co &utm_medium=prtnr&utm_content=Mar2515&utm_campaign=PartBadge&pcampaignid=MK T-Other-global-all-co-prtnr-py-PartBadge-Mar2515-1) iOS link (https://geo.itunes.apple.com/us/app/7kt-pac1200/id1091508286?mt=8) Android screen (https://play.google.com/intl/en_us/badges/images/generic/de-play- badge.png) iOS screen (http://linkmaker.itunes.apple.com/images/badges/en-us/badge_appstore-lrg.svg) 7KT PAC1200 multichannel current measuring system...

  • Page 48: Home

    Operator control (software) 5.2 Application for mobile devices 5.2.2 Home After a multichannel current measuring system has been selected, the Home page showing the current energy consumption appears. Further information on available on the Home page: ● Date and time ●...
  • Page 49 Operator control (software) 5.2 Application for mobile devices Figure 5-15 Start page of the application 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 50: Statistics

    Operator control (software) 5.2 Application for mobile devices 5.2.3 Statistics The Statistics view offers the following evaluations: ● Overall consumption ● Individual system consumption ● Individual consumption ● Consumption of the individual sensors Consumption (top right) can be shown in: ●...
  • Page 51 Operator control (software) 5.2 Application for mobile devices Overall consumption Overall consumption is visualized using a bar chart. 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...
  • Page 52 Operator control (software) 5.2 Application for mobile devices Individual system consumption Individual system consumption is displayed in the form of a pie chart. The sensors selected in the Sensor settings are displayed here in a direct comparison. Individual consumption In the case of individual consumption, all selected sensors are represented underneath each other in a horizontal bar chart.

  • Page 53: Current Values

    Operator control (software) 5.2 Application for mobile devices 5.2.4 Current values The current values are represented in real time, exactly as in the browser-based web application. It is possible to stop the recording here. The latest current (power) values are also shown in the current values.
  • Page 54 Operator control (software) 5.2 Application for mobile devices Figure 5-17 Current values - Current values Another method of accessing the Data Manager via the application is to use the energy stopwatch. This can be started and stopped again. 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 55: Service And Maintenance

    Service and maintenance Error messages The Status LED does not light up Problem: The Data Manager is not supplied with power. Solution: Ensure that at least the line conductor L1 and the neutral conductor N are connected to the Data Manager. The Status LED lights up or flashes red.

  • Page 57: Technical Data

    Technical data Interfaces (standard) ● LAN (10 / 100 Mbits) ● RS485 for data transfer by means of Modbus RTU Voltage and current inputs Rated voltage 230 / 400 V AC Operating voltage 230 V ± 10 % Frequency 50 Hz ± 5 % Intrinsic consumption Voltage circuit <...
  • Page 58 Technical data Measuring accuracy Data Manager Voltage ± 0.5 % Current ± 0.5 % Active power ± 1.0 % Apparent power ± 1.0 % Reactive power ± 1.0 % Power factor (p.f.) ± 1.0 % Active energy Class 1 Reactive energy Class 1 When using external current transformers, the respective measuring accuracy must be taken into account.
  • Page 59 Technical data Operating conditions ● Ambient temperature: - 25°C ... + 45°C ● Storage temperature: - 25°C ... + 70°C ● Relative humidity: – Up to 75 % annual average – Up to 95 % on up to 30 days / year Mechanical data ●...

  • Page 60: Dimension Drawings

    Technical data 7.1 Dimension drawings Table 7- 1 Connector assignments Pin direct Pin indirect Description Supply voltage 9 V RS485-B RS485-A Ground Dimension drawings 7.1.1 Dimensions of the Data Manager View from the right and from the front 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 61: Dimensions Of The Sensor Bar

    Technical data 7.1 Dimension drawings View from above and from below 7.1.2 Dimensions of the sensor bar Sensor bar with three sensor slots 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...
  • Page 62 Technical data 7.1 Dimension drawings Sensor bar with six sensor slots 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...
  • Page 63 Technical data 7.1 Dimension drawings Sensor bar with nine sensor slots 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...
  • Page 64 Technical data 7.1 Dimension drawings Sensor bar with twelve sensor slots 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 65: Dimensions Of The Sensors On The Sensor Bar

    Technical data 7.1 Dimension drawings 7.1.3 Dimensions of the sensors on the sensor bar 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 67: Appendix

    What is the measuring accuracy of the overall system? Data Manager 1 %, overall system 2 % At which intervals are the sensor values transferred to Siemens Data Manager? < 1 second In which languages can the system be configured? In German and English.

  • Page 68: Modbus Register List

    Appendix A.2 Modbus register list Modbus register list Register overview Start address End address Start address End address Size Description (decimal) (decimal) (hexadecimal) (hexadecimal) 0x0000 0x0091 See 4.1 Internal, immediate registers 0x0200 0x0317 See 4.2 Internal energy registers (meters) 8192 8243 0x2000 0x02033...
  • Page 69 Appendix A.3 Internal registers 0x0012 0x0013 0x03 Unit 32 0.1 VA 1-0:10.4.0*255 Apparent power - 0x0014 0x0015 0x03 — — — (reserved) 0x0016 0x0017 0x03 — — — (reserved) 0x0018 0x0019 0x03 Unit 32 0.001 (no 1-0:13.4.0*255 Power factor unit) 0x001A 0x001B 0x03...
  • Page 70 Appendix A.3 Internal registers 0x0054 0x0055 0x03 Unit 32 0.1 var 1-0:43.4.0*255 Reactive power + (L2) 0x0056 0x0057 0x03 Unit 32 0.1 var 1-0:44.4.0*255 Reactive power - (L2) 0x0058 0x0059 0x03 — — — (reserved) 0x005A 0x005B 0x03 — — —...
  • Page 71 Appendix A.3 Internal registers Internal energy registers (meters) Start Start Size R/W Func- Type Units OBIS code Description address address address address tion (deci- (deci- (hexa- (hexa- codes mal) mal) decimal) decimal) 0x0200 0x0203 0x03 Unit 64 0.1 Wh 1-0:1.8.0*255 Active power 0x0204 0x0207...
  • Page 72 Appendix A.3 Internal registers 0x0274 0x0277 0x03 Unit 64 0.1 VAh 1-0:30.8.0*255 Apparent power - (L1) 0x0278 0x027B 0x03 — — — (reserved) 0x027C 0x027F 0x03 — — — (reserved) 0x0280 0x0283 0x03 — — — (reserved) 0x0284 0x0287 0x03 —...
  • Page 73 Appendix A.3 Internal registers 0x0300 0x0303 0x03 — — — (reserved) 0x0304 0x0307 0x03 — — — (reserved) 0x0308 0x030B 0x03 — — — (reserved) 0x030C 0x030F 0x03 — — — (reserved) 0x0310 0x0313 0x03 Unit 64 0.1 VAh 1-0:69.8.0*255 Apparent power + (L3) 0x0314...
  • Page 74 40003 40003 0x03 C_SunSp Unit regis- Length of the ec_Length ters common model 40004 40019 0x03 C_Manufa Series Manufacturer's Siemens AG cturer (32) name: 40020 40035 0x03 C_Model Series Model name PAC1200 (32) 40036 40043 0x03 C_Options Series Manufacturer- —...
  • Page 75 Appendix A.3 Internal registers 40077 40077 0x03 M_AC_Vol Unit M_AC_Vol Phase A to 1-0:32.4.0*255 tage_AN tage_SF neutral AC volt- 40078 40078 0x03 M_AC_Vol Unit M_AC_Vol Phase B to 1-0:52.4.0*255 tage_BN tage_SF neutral AC volt- 40079 40079 0x03 M_AC_Vol Unit M_AC_Vol Phase C to 1-0:72.4.0*255 tage_CN...
  • Page 76 Appendix A.3 Internal registers 40092 40092 0x03 M_AC_VA Unit M_AC_VA Total AC appar- > 0 ≙ 1- ent power (total 0:9.4.0*255 of active phas- < 0 ≙ 1- 0:10.4.0*255 40093 40093 0x03 M_AC_VA Unit M_AC_VA Phase A AC > 0 ≙ 1- apparent power 0:29.4.0*255 <...
  • Page 77 Appendix A.3 Internal registers 40104 40104 0x03 M_AC_PF Unit M_AC_PF Phase B power 1-0:53.4.0*255 factor -1000…+1000 40105 40105 0x03 M_AC_PF Unit M_AC_PF Phase C power 1-0:73.4.0*255 factor -1000…+1000 40106 40106 0x03 M_AC_PF Unit AC power factor scaling factor** 40107 40108 0x03 M_Export Unit...
  • Page 78 Appendix A.3 Internal registers 40140 40140 0x03 M_Energy Unit Apparent energy _VA_SF scaling factor** 40141 40142 0x03 M_Import_ Unit VARh M_Energy Quadrant 1: 0x80000000 VARh_Q1 _VAR_SF total, imported reactive energy 40143 40144 0x03 M_Import_ Unit VARh M_Energy Phase A - quad- 0x80000000 VARh_Q1 _VAR_SF...

  • Page 79: Sensor Registers

    Appendix A.4 Sensor registers 40173 40173 0x03 M_Energy Unit Reactive energy _VAR_SF scaling factor** 40174 40175 0x03 M_Events Unit Event flags - indicates that it is valid 40176 40176 0x03 C_SunSp Unit SunSpec end 0xffff ec_DID model block 40177 40177 0x03 C_SunSp Unit...
  • Page 80 Appendix A.4 Sensor registers Sensor registers Start Start Size R/W Func- Type Units OBIS code Descrip- Source address address address address tion tion type (deci- (deci- (hexa- (hexa- codes mal) mal) decimal) decimal) 61440 61443 0xF000 0xF003 0x10 — — —...

  • Page 81: Esd Guidelines

    ESD guidelines Electrostatic sensitive devices (ESD) ESD components are destroyed by voltage and energy far below the limits of human perception. Voltages of this kind occur as soon as a device or an assembly is touched by a person who is not electrostatically discharged. ESD components which have been subject to such voltage are usually not recognized immediately as being defective, because the malfunction does not occur until after a longer period of operation.
  • Page 82 ESD guidelines B.1 Electrostatic sensitive devices (ESD) ESD seat ESD standing position ESD seat and ESD standing position Protective measures Conductive floor ESD table ESD footwear ESD smock ESD bracelet Cubicle ground connection 7KT PAC1200 multichannel current measuring system System Manual, 11/2016, 2514374103-02...

  • Page 83: Glossary

    Glossary Application Application software or computer program that executes a useful function for the user. Balancing counter The balancing counter calculates the total of energy flows of all three phases, and registers this total according to the direction of the energy flow. CSV file This file format describes the structure of a text file for saving or exchanging simply structured data.

  • Page 85: Index

    Index Android device Data export Requirements, 46 Settings, 40 Application Data Manager Current values, 53 Dimensions, 60 Individual system consumption, 52 Introduction, 15 Introduction, 46, 48 Overview, 16 Overall consumption, 51 Device Start, 46 Settings, 36 Statistics, 50 Diagnostics option Applications, 14, 20 LEDs, 21 Network LED, 21...
  • Page 86 Index Installment, 32 Start-up Intrinsic consumption, 57 Settings, 28 Introduction Statistics, 30 Application, 46 Application, 50 iOS device Storage, 81 Requirements, 46 System environment, 22 Browser application, 27 Settings, 27 Network Settings, 39 Tariff Settings, 43 Technical specifications, 57 Intrinsic consumption, 57 Overall consumption Measuring accuracy, 58 Application, 51...
