User Guide
BnA6 Advance™ & BNR Advance™
Note Validator & Note recycler
V2.0 EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BNA6 ADVANCE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CPI BNA6 ADVANCE

Summary of Contents for CPI BNA6 ADVANCE

  • Page 1 User Guide BnA6 Advance™ & BNR Advance™ Note Validator & Note recycler V2.0 EN...
  • Page 2 85% at +40 °C (104 °F) (non-condensing) Compliance BNA6 Advance & BNR Advance note recycler has been evaluated and is compliant with UL/CSA/IEC 62368-1, audio/video, information, and communications technology equipment – Part 1: Safety requirements and UL-756 standard for safety coin currency changers and actuators.

  • Page 3: Table Of Contents

    Assembling the note validator/recycler ................... 16 Operate ........................18 Getting BNA6 Advance & BNR Advance note validator and recycler ready for initial operation ..18 Note validator/recycler behavior during power-up and reset ............19 Operating BNA6 Advance & BNR Advance note validator and note recycler ........20 4.3.1...
  • Page 4 Table of Contents BNA6 Advance & BNR Advance Note Validator and Note Recycler 4.4.2.1 Quality requirements for banknotes ..............................35 Controlling BNA6 Advance & BNR Advance note validator and note recycler ........35 4.5.1 Enabling/disabling banknote denominations ..................... 35 4.5.2 Returning new banknote denomination as change (note recycler only) ............

  • Page 5: About This User Guide

    This chapter is designed to help the reader navigate easily within this user guide. This user guide is meant for operators and describes the design and function of the BNA6 Advance & BNR Advance note validator and note recycler. Afterwards, chapters 3 and 4 explain the necessary steps for unpacking, assembling, and operating the note validator/recycler.

  • Page 6: About Note Validator And Note Recycler

    • functional elements required for the operation of the note validator/recycler The BNA6 Advance & BNR Advance note validator and recycler is designed to validate different banknotes of one currency inserted into the device for specific properties. Only valid banknotes are accepted and transported to the cash box for storage purposes. Suspicious or damaged banknotes will be rejected.

  • Page 7: Bnr Note Recycler Models

    BNA6 Advance & BNR Advance Note Validator and Note Recycler About note validator and note recycler 2.1.2 BNR note recycler models The note recycler models differ in the chassis size, recycling and cash box capacity, with the first digit of the model name defining the number of optional recycling, loading modules, and cash box and the two digits following the hyphen specifying how many recycling and loading modules are included.

  • Page 8: Bezel Versions

    About note validator and note recycler BNA6 Advance & BNR Advance Note Validator and Note Recycler 2.1.3 Bezel versions Standard bezel in black or gray Flush bezel Fig. 11: Standard bezel Fig. 12: Flush bezel 2.1.4 Cash box versions The cash box is available in three different capacity...

  • Page 9: Acceptance Module

    BNA6 Advance & BNR Advance Note Validator and Note Recycler About note validator and note recycler The note recycler consists of an: Acceptance module Cash box One or two recycling modules Optional loading module Loading module (option) Recycling modules Cash box Acceptance module Fig.

  • Page 10: Loading Module (Note Recycler Only)

    About note validator and note recycler BNA6 Advance & BNR Advance Note Validator and Note Recycler The individual recycler configuration determines what denominations are to be directed to the recycling modules or to the cash box. how many banknotes should remain in each recycling module as minimum change stock for the next day, which cannot be transferred to the cash box.

  • Page 11: Main Components

    BNA6 Advance & BNR Advance Note Validator and Note Recycler About note validator and note recycler Main components Fig. 22: Note recycler front and rear view Front and rear view 1. Latch button – open upper rear flap 12. Cash box handle – remove cash box 2.
  • Page 12 About note validator and note recycler BNA6 Advance & BNR Advance Note Validator and Note Recycler Cash box 1. Cash box cover 2. Lock – open cash box 3. Indicator – ready for insertion state 4. Handle – remove cash box Fig.

  • Page 13: Key Locks

    BNA6 Advance & BNR Advance Note Validator and Note Recycler About note validator and note recycler 2.4.1 Key locks To keep your cash safe the note validator/recycler units are secured by means of a so-called interlock [1] system permanently installed inside of the metal chassis guaranteeing that all cash modules are locked in place with a lock and a lever.
  • Page 14 About note validator and note recycler BNA6 Advance & BNR Advance Note Validator and Note Recycler Status LED Flashing code Meaning Banknote insertion and acceptance disabled by host machine. Please insert banknote. Flashing Rejecting banknote inserted. Please pull out banknote.

  • Page 15: Install

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Install Install This chapter • provides information on unpacking the note validator/recycler • lists the scope of delivery • describes how to assemble the note validator/recycler Unpacking the note validator or note Recycler The note validator/recycler comes in two boxes.

  • Page 16: Assembling The Note Validator/Recycler

    Install BNA6 Advance & BNR Advance Note Validator and Note Recycler Assembling the note validator/recycler Before the note validator/recycler can be installed in the host machine the acceptance module has to be installed on the top of the note validator/recycler chassis. This chapter and user guide only describes the assembly of the note validator/recycler.
  • Page 17 BNA6 Advance & BNR Advance Note Validator and Note Recycler Install Fig. 30: Connecting acceptance module Fig. 29: Locking acceptance module into place Lift rear green lever [4], hold it [C] and simultaneously slide acceptance module towards the front as far as it will go and until it clicks into place [C].

  • Page 18: Operate

    Chassis is grounded properly (see separate Integration Manual). Host machine and note validator/recycler are powered up and the latter is reset (see chapter 4.1 “Getting BNA6 Advance & BNR Advance note validator and recycler ready for initial operation”, p. 18).

  • Page 19: Note Validator/Recycler Behavior During Power-Up And Reset

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate Note validator/recycler behavior during power-up and reset After powering up the note validator/recycler, in a next step, the validator/recycler has to be reset by the host machine. Depending on the number of note validator/recycler modules the reset sequence takes approximately 15 to 25 seconds.

  • Page 20: Operating Bna6 Advance & Bnr Advance Note Validator And Note Recycler

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operating BNA6 Advance & BNR Advance note validator and note recycler This chapter describes how to open the interlock system, chassis flaps, handle the cash box, acceptance module, as well as loading and recycling module of a note recycler.

  • Page 21: Opening And Closing Top (Acceptance Module) Flaps

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate 4.3.2.1 Opening and closing top (acceptance module) flaps The acceptance module is equipped with two flaps, a top and a rear flap. The rear flap can only be opened when the top flap is closed. To...

  • Page 22: Opening And Closing Lower Rear (Spine) Flap

    Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler 4.3.2.2 Opening and closing lower rear (spine) flap From the rear side of the note validator/recycler, raise the yellow latch [1] on the rear side [A] and simultaneously unfold the spine flap [2] [A].

  • Page 23: Removing And Reinstalling Cash Box

    Unfold [A] the yellow cash box handle [1] and pull the cash box out of the chassis [B], if necessary, bring the handle back into its initial position. Reinstall a rearmed cash box or empty the module (see Chapter 4.4.1 “Emptying BNA6 Advance & BNR Advance note validator and note recycler”, p. 31).

  • Page 24: Removing, Opening, And Reinstalling Optional Loading Module (Note Recycler Only)

    Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler 4.3.4 Removing, opening, and reinstalling optional loading module (note recycler only) The loading module is double-locked in order to secure the module in place within the note recycler (interlock system) and to keep the cash safe within the loading cassette.
  • Page 25 BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate Unlatch [D] the yellow lever [3] to lift the maximum level detection plate [4] [E]. The level flag [5] is no longer green but orange now. Continue with refilling banknotes (see chapter 4.4.2 “Refilling loading module of BNR Advance note recycler”, p.
  • Page 26 Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler To reinstall the loading module: Reinsert the cassette until it locks in place [A]. Relock the interlock system (see chapter 4.3.1 “Unlocking and relocking interlock system”, p. 20). Reset the note recycler.

  • Page 27: Removing And Reinstalling Recycling Module(S) (Note Recycler Only)

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate 4.3.5 Removing and reinstalling recycling module(s) (note recycler only) To remove the recycling cassette(s) you need the interlock system key and the recycling cassettes’ keys. To be able to access the lower recycling cassette B, the upper recycling cassette A (see Fig. 19 on p. 9) has to be removed.
  • Page 28 Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler Reinstall the lower recycling cassette B prior to reinstalling the upper recycling cassette A: If removed, reinstall the lower recycling cassette [A]. If not removed, reinstall the upper recycling cassette [B].

  • Page 29: Removing And Reinstalling Acceptance Module

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate 4.3.6 Removing and reinstalling acceptance module Please pay attention to the following safety instructions when removing and reinstalling the acceptance module: Heavy object. The recycler/validator can weigh more than 25 kg (55 lb).
  • Page 30 Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler Detach acceptance module with care [D]. Fig. 54: Removing acceptance module To reinstall the acceptance module with the green shockblocker lever still pulled out: Carefully place acceptance module on the top of the chassis [A] with its hood outside the chassis and its slotted holes [1] aligned with the chassis’...

  • Page 31: Handling Cash

    This chapter describes how to empty the cash box and refill the recycler with banknotes. 4.4.1 Emptying BNA6 Advance & BNR Advance note validator and note recycler cash box To empty the cash box of the note validator or recycler you need the interlock system key and the cash box key.
  • Page 32 Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler Remove the cash box (see chapter 4.3.3 “Removing and reinstalling cash box”, p. 23). To replace the full cash box with another empty cash box follow the re-installation steps for the cash box.
  • Page 33 BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate Close the cassette cover again [E]. Press on the top of the cassette [F] to fully close the cassette simultaneously turn the key clockwise as far as it will go [F].

  • Page 34: Refilling Loading Module Of Bnr Advance Note Recycler

    Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler 4.4.2 Refilling loading module of BNR Advance note recycler The optional loading module is empty and can no longer feed the recycling modules with banknotes when the recycling and loading modules’ status LEDs are flashing red (regularly every second). A status message is sent to the host machinne.

  • Page 35: Quality Requirements For Banknotes

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Operate 4.4.2.1 Quality requirements for banknotes Banknotes filled in the loading module must meet the following requirements: No holes, tear, folds Banknote ends may not be folded or torn by more than a quarter of its length!

  • Page 36: Readjusting Loading Module To New Banknote Size (Note Recycler Only)

    Operate BNA6 Advance & BNR Advance Note Validator and Note Recycler 4.5.2.1 Readjusting loading module to new banknote size (note recycler only) If the loading module is supposed to store another denomination, the loading module may need to be readjusted to match the size of the banknote to be stored.

  • Page 37: Troubleshoot

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Troubleshoot Troubleshoot This chapter describes how to • locate and fix errors or malfunctions using the status LEDs • clear a banknote jam Locating and fixing errors using status LEDs...
  • Page 38 Troubleshoot BNA6 Advance & BNR Advance Note Validator and Note Recycler Steady on/ Status LEDs flashing code Meaning Remedy/hints Faster Banknote jammed/stopped in transport area. Clear banknote jam flashing Banknote jammed in loading module. (see 5.2.4, p. 42) Faster Banknote jammed/stopped in transport area.

  • Page 39: Clearing Banknote Jam

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Troubleshoot Steady on/ Status LEDs flashing code Meaning Remedy/hints • Wrong configuration • Host machine to reset note validator/recycler • Make sure the SW configuration matches the unit's physical configuration •...

  • Page 40: Clearing Banknote Jam In Acceptance Module's Feeder

    Troubleshoot BNA6 Advance & BNR Advance Note Validator and Note Recycler 5.2.1 Clearing banknote jam in acceptance module’s feeder To retrieve the jammed note(s) and return functionality to the machine please check the note validator’s/recycler’s feeder for jammed notes: Open both acceptance module flaps (see chapter 4.3.2 “Opening and closing chassis flaps”, p.

  • Page 41: Clearing Banknote Jam In Spine

    BNA6 Advance & BNR Advance Note Validator and Note Recycler Troubleshoot 5.2.2 Clearing banknote jam in spine To retrieve the jammed note(s) and return functionality to the machine please check the passage from the acceptance module to the spine and the spine for jammed notes: Open spine flap (see chapter 4.3.2 “Opening and closing chassis flaps”, p.

  • Page 42: Clearing Banknote Jam In Passage From Acceptance Module To Cash Box

    Open and close the cash box again to rearm the cash box (see chapter 4.4.1 “Emptying BNA6 Advance & BNR Advance note validator and note recycler cash box”, p. Error! Bookmark not defined.). The cash box indicator is green. Now the cassette can be reinstalled.

  • Page 43: List Of Figures

    BNA6 Advance & BNR Advance Note Validator and Note Recycler List of figures List of figures Fig. 1: BNR6 Advance note validator ............6 Fig. 39: Closing lower rear flap ............. 22 Fig. 2: BNR Advance note recycler ............6 Fig.
  • Page 44 Notes ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________ ___________________________________________________________________________________________________________...
  • Page 45 (natural or computer) without the prior written permission of Crane Payment Innovations (CPI). CPI reserves the right to change the product specifications at any time. While every effort has been made to ensure that the information in this publication is accurate, CPI disclaims any liability for any direct or indirect losses (howsoever caused) arising out of use or reliance on this information.
  • Page 46 C O N T A C T U S Crane Payment Innovations Corporate HQ 3222 Phoenixville Pike, Suite 200 Malvern, PA 19355 support@cranepi.com CPI support...

This manual is also suitable for:

Bnr advanceBnr6 advanceBna6 advance mBna6 advance lBnr4-21 advanceBna4-10 advance ... Show all
