Intended use and Compliance
Intended use and Compliance
Before using the BNA6 Advance & BNR Advance note validator and note recycler for the first time, please carefully read this user guide, and
in particular the safety instructions, at least once. This is to ensure that the contents of this user guide have been understood and the reader
knows how to operate the note validator and note recycler.
Intended use
The BNA6 Advance & BNR Advance note validators and note recyclers are intended to be integrated as a peripheral within a host machine.
Both, note validators and note recyclers are designed to validate, denominate, and store banknotes. Beyond that, the BNRrecycle banknotes
collected in recycling modules as change. Use the BNA6 Advance & BNR Advance note validator and note recycler exclusively for this
purpose. Under no circumstances can the manufacturer be held liable for any damage or loss resulting from improper use of the equipment.
Technical specifications
Voltage operating range 24 V DC -10% +20%
Ripple
UL current input rating
Current consumption
Inrush current protection Internally limited to 9 A nominal during power on
Temperature range
Relative humidity (RH)
Compliance
BNA6 Advance & BNR Advance note recycler has been evaluated and is compliant with UL/CSA/IEC 62368-1, audio/video, information, and communications technology equipment – Part 1: Safety
requirements and UL-756 standard for safety coin currency changers and actuators.
BNA6 Advance & BNR Advance note recycler is designed and complies with the following European directives:
2014/30/EU electromagnetic compatibility directive
2014/35/EU low voltage directive directive
2011/65/EU amended 2015/863/EU restriction of hazardous substances directive
The BNR & BNA6 meet Class B radiated emissions limits in accordance with EN55032:2015
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
2
BNA6 Advance & BNR Advance Note Validator and Note Recycler
300 mVpp max.
5 A
Peak at 24 V DC (when using loading module):
During extreme conditions (at 21.6 V DC and 0 °C): up to 10 A
Standby (at 24 V DC):
0 °C to 60 °C (32 °F to 140 °F)
85% at +40 °C (104 °F) (non-condensing)
Published by CPI
8 A–9 A
0.5 A (12 W)
