Polycom RPX HD User Guide
3–12
Enhanced User Interface
To view content with a document camera when you are using the Enhanced UI:
Touch
Content at the top of the Touch Panel screen. (You will
1
see this button only if there is a document camera connected to the
system.)
The Content screen for the Enhanced UI appears as shown in
page
3-8.
Touch
Doc Cam.
2
The following then occurs:
— The color of the
— The buttons on the Content screen for the Enhanced UI become
selectable.
Figure 3-7
(with Selectable Document Camera Buttons)
— The document camera powers on in about three seconds.
— If your suite is equipped with a VZ-C12
field appears on the main table.
spotlight field on an RPX HD 400 Series main table. The RPX HD 200
Series main table has similar placement.
Doc Cam button changes to yellow.
Content Screen — Enhanced UI
2
document camera, a spotlight
Figure 3-8
shows the location of the
Figure 3-3
on
