Viewing Content

3–6
For example, if you call a Polycom TPX HD room from an RPX HD 200 Series
suite, the image on the displays in the RPX suite adjusts for the 16:9 TPX HD
room. Therefore, this is what you can expect to see on the displays in the RPX
suite:
Figure 3-1
Likewise, in the TPX HD 306M room, the image automatically adjusts so the
people in that room see a real-size view of the people in the RPX suite. This is
the view in the TPX HD 306M room:
People on left half of
RPX HD 200 Series room
Figure 3-2
Your RPX enables you to view content (such as slides, spreadsheets, or other
documents) during your telepresence conference. You can also receive content
from the other site(s) in the conference.
You can display content at your site using a laptop, an optional document
camera, or an optional integrated PC. Whenever you display or receive
content, that content automatically appears on the tabletop content monitors.
If you are using the Polycom RPX suite for a regular meeting rather than for a
telepresence conference, you can still view content on the content monitors.
Unused display area
16:9
Left side of
TPX HD room
Unused display area
Example of an Adjusted Display in an RPX Suite
Area above people's heads not shown
People on right half of
RPX HD 200 Series room
Example of an Adjusted Display in a TPX HD 306M Room
Unused display area
16:9
Right side of
TPX HD room
Unused display area
Right display (not
used in a call with an
RPX HD 200 Series)
