Digital System Sensors
Table 2-2 lists the digital system sensor descriptions.
Table 2-2 Digital System Sensor Descriptions
Sensor Sensor Position 1
Door Closed Door is closed.
Key lock Door locked.
Gripper Home Gripper is located in the
home position.
Cart seated Cartridge is correctly seated.
Vertical Mode Tower unit
Analog System Sensors
Table 2-3 lists the analog system sensor descriptions.
Table 2-3 Analog System Sensor Descriptions
Sensor
Temperature
+12V
-12V
+24V
SPARCstorage Library X-Option Rack-mounted User's Guide—June 1995
Sensor Position 0
Door is open.
Door is unlocked.
Gripper is not located in the
home position.
Cartridge is not correctly
seated.
Rack-mounted unit
Description
Indicates the temperature of the tape library in
degrees C.
Indicates the output of the 12-volt power supply in
milliVolts.
Indicates the output of the negative 12-volt power
supply in milliVolts.
Indicates the output of the 24-volt power supply in
milliVolts.
