Cycle L Axis
Cycle Solenoid
2.4.3.1 Self Test
The following actions occur during the Self Test diagnostic:
•
The gripper fingers of the CHM move to the home position.
•
The CHM cycles the long and short axes once, then moves to the home
position at the bottom of the long axis.
1. Select the Maintenance Menu by pressing
2. Select the Diagnostics Menu by pressing
3. Select Self Test by pressing
To abort the Self Test diagnostic, press Escape and Enter.
2.4.3.2 Position to Element Test
This diagnostic positions the CHM in front of a tape drive, cleaning cartridge
slot, or a particular slot in the cartridge holder.
1. Select the Maintenance Menu by pressing
2. Select the Diagnostics Menu by pressing
3. Select Position to Element by pressing
The following screen is displayed:
Set Destination
↑ Increase
↓ Decrease
SPARCstorage Library Menu Functions
Causes the CHM to move end to end along the long axis
(the axis where the CHM moves up and down). You
must specify the number of cycles the CHM must
perform in increments of 10 (up to 250).
Cycles the door solenoid, used to lock the front door.
You must specify the number of cycles the CHM must
perform in increments of 10 (up to 250).
↓ ↑
or
↓ ↑
or
↓ ↑
or , then Enter.
↓ ↑
or
↓ ↑,
or
↓ ↑
or , then Enter.
0
↓
2
, then Enter.
, then Enter.
, then Enter.
then Enter.
2-17
