2.4.3.7 Home Gripper Test
The Home Gripper test closes and opens the gripper on the CHM.
1. Select the Maintenance Menu by pressing
2. Select the Diagnostics Menu by pressing
3. Select Home Gripper by pressing
The gripper on the CHM closes and opens.
To abort this diagnostic, press Escape and Enter.
2.4.3.8 Home CHM Test
The following actions occur during the Home CHM test:
•
CHM moves in and out on the short (horizontal) axis
•
CHM moves down and up on the long (vertical) axis
•
Gripper of the CHM closes and opens
1. Select the Maintenance Menu by pressing
2. Select the Diagnostics Menu by pressing
3. Select Home CHM by pressing
To abort this diagnostic, press Escape and Enter.
2.4.3.9 Cycle Pick/Place Test
The Cycle Pick/Place test picks a cartridge from the element you specify and
places it back in the same element. You can specify the number of times you
want this test repeated.
1. Select the Maintenance Menu by pressing
2. Select the Diagnostics Menu by pressing
3. Select Cycle Pick/Place by pressing
The system displays the following screen:
Set Source
↑ Increase
↓ Decrease
SPARCstorage Library Menu Functions
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑,
or then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or , then Enter.
0
2
2-21
