Appendix G: Power Consumption
nROK 7251-WI-7C4IP
Item Device
Configuration
S0 State Full State + Loading
1
i7-9700TE (+ PoE 60W)
2 S3 State Full State Sleep Mode
3 IGN OFF Full State IGNITION OFF
*WWAN: Enable wakeup function of WWAN module
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Test Case
Voltage Current(A)
24V 7.43
36V 5.18
48V 3.89
72V 2.6
110V 1.68
24V 0.71
24V wake up WWAN 0.717
110V 0.14
110V wake up WWAN 0.14
24V 0.206
24V wake up WWAN 0.212
36V 0.134
36V wake up WWAN 0.139
48V 0.1
48V wake up WWAN 0.103
72V 0.066
72V wake up WWAN 0.072
110V 0.021
110V wake up WWAN 0.021
Result
Average Peak
Watt(W) Current(A) Watt(W)
183.12 10.62
186.48 7.17
186.72 5.11
187.2 3.25
184.8 2.2
17.04 N/A
17.208 N/A
15.4 N/A
15.4 N/A
4.944 N/A
5.088 N/A
4.824 N/A
5.004 N/A
4.8 N/A
4.944 N/A
4.72 N/A
5.18 N/A
2.31 N/A
2.31 N/A
90
254.88
258.12
245.28
243.75
242
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
