Appendix B:
Metasys System Overview
The figure below summarizes the Metasys system hardware architecture.
N1 LAN
Operator
Modem
Workstation
Internal Module
2 Slot
Submodule
Printer
NCU
L2 Bus
5 Slot
NCU
N2 Bus
C260
C210
1 Slot
NEU
ILC
Figure 28: Metasys System Hardware Architecture
76 Network Terminal User's Manual
