Correcting a
Mistake
Penetrating the
Metasys System
Selecting Screen
Options and
Commands
The procedure for entering information is:
1. Drag your finger across the Touchpad until the cursor points to and
highlights the character you want to enter.
2. Press the Touchpad at that point to select the character, then press
ENTER. If you are entering a password, the characters you select
appear on the screen as asterisks (*).
3. Repeat this process until you've selected and entered all the
characters, then select EXECUTE (or CONTINUE, depending on the
screen displayed).
4. Press ENTER to let the system know your entry is complete.
If you make a mistake, select ERASE, then press ENTER to delete the
last character.
To perform most procedures, you'll have to penetrate the Metasys
Network to select a system and/or object. Each layer of penetration
displays a new screen with Screen Options and Commands applicable to
that screen.
The Screen Options are selectable only when they are valid options for
the particular procedure you are performing.
You'll use the Screen Options to display Alarm or Override summaries,
access a system or object, and sequence through procedures.
The table on the next page lists the Screen Options, the screens on which
they may appear, and the function of each option.
To select an option:
1. Drag your finger across the Touchpad to move the cursor to that
option.
2. When the option highlights, press the area on the Touchpad that
corresponds to the location of the option.
Network Terminal User's Manual 15
