Status
Summaries
A Status Summary shows the current condition of an object (for instance,
alarm or override condition). The STATUS command displays up to
eight conditions for an object at a time. The conditions are listed in order
of importance.
To display a Status Summary, select a system, an object, then the
STATUS command, shown as an asterisk (*) in the Command area.
To exit, select PREVIOUS, then
ENTER.
* Object Status Summary
System ID
AHU1
Status
* O8A_DMPR
Object Data
Hardware Override
Offline
Disabled
Status
Triggers Are Locked
Reports Are Locked
Figure 10: AOD Status Summary Screen
100% Open
Network Terminal User's Manual 27
LOG OFF
HOME
CONTINUE
