Display Screen
If the NT Emulator does
not detect the presence of
a mouse, a block cursor,
as illustrated, will be
displayed.
The NT screen is displayed as a window on the PC's monitor. (See
example below.) On the bottom left-hand side of the PCs display is a
status line indicating the communication port and baud rate entered.
A reminder that the ESC key exits the emulation is also displayed.
DIAL UP appears in the middle right-hand side to indicate remote
connection capability.
If the PC has a mouse installed, the cursor will be in the shape of an
arrow.
JOHNSON
CONTROLS
PORT: COM2 9600
Figure 20: PC Display with No Mouse Installed
NETWORK TERMINAL
PRESS ESC TO EXIT
