Overview of the
Network Terminal
Introduction
This section introduces you to the Network Terminal, including its
capabilities and features.
The end of this section describes this manual's structure and intended
audience.
The Network Terminal (NT) is a simple, lightweight, portable operator
interface to the Metasys® system. A standard telephone jack connects
the NT to any Network Control Module (NCM) on the Metasys system.
(For the NCM45x0-2 model, the NCM4500 NT Cable Kit is required.)
This direct connection allows for easy access to any system functions
available for your password level.
You can also connect the NT to the NCM from remote locations (up to
one mile) on a separate NT trunk. (This capability is not available with
the NCM45x0-2 model.)
The NT provides some of the functions available from the standard
Operator Workstation in one neat, easy
NT is as simple as making a phone call! All you do is:
1. Establish the connection--plug the NT in to any NCM or Remote NT
Jack.
2. Introduce yourself--log on and enter your password.
3. Talk to the Metasys system--enter data and select options.
4. Listen to the Metasys system--follow screen instructions, view
summaries.
5. End your conversation--log off.
- -
to use package. In fact, using the
