Listening to the
Metasys System
System ID Screen
The Metasys system talks to you by displaying the information you
request.
After you log on, the System ID screen appears. It lists all the systems
accessible to your password. From this screen, you can:
either select the LOG OFF, CLOCK, OVERRIDE, or ALARM
options
or select a system, then press ENTER to display that system's objects
For a summary, select ALARM or
OVERRIDE. For data, select a
system name, then press ENTER.
AHU1
BASEMENT
AHU3
System IDs
AHU5
DIVERSE
Figure 8: System ID Screen
The CLOCK Screen Option allows you to set the system date and time,
adjust daylight saving times, and specify Holiday, Alternate, and Regular
periods. See Setting the Clock for more information on this option.
The ALARM and OVERRIDE Screen Options display summaries of any
system IDs that have objects in ALARM or OVERRIDE. Just select a
system, select ALARM or OVERRIDE, then press ENTER. See
Requesting Information for details on summaries.
To see the Object ID screen displaying all the objects in a system, simply
select that System ID and press ENTER.
AHU2
OVERRIDE
1STFLOOR
AHU4
2NDFLOOR
PAGEDOWN
AHU5
Page 1
Network Terminal User's Manual 23
LOG OFF
CLOCK
ALARM
SYSTEMID
