Alarm and
Override
Summaries
26 Network Terminal User's Manual
Requesting Information
This section explains how to request Alarm, Override, Status, Limit,
History Information, and Hold Summaries and the HELP command.
The Alarm and Override Summaries options are available on the System
ID screen. Status, Limit, and History Summaries are available when you
select an object.
To display a summary of all systems that have objects in alarm or
override, select the ALARM or OVERRIDE Screen Option from the
System ID screen.
For a summary, select ALARM or
OVERRIDE. For data, select a
system name, then press ENTER.
AHU1
BASEMENT
AHU3
System IDs
AHU5
DIVERSE
Figure 9: System ID Screen
To see which objects are in alarm or override, select a system from the
Alarm or Override Summary screen, then press ENTER. If the data is not
readily available from the NCM, the screen displays COLLECTING
DATA, PLEASE WAIT ...
You can select an object displayed on the summary screen, then select
any available Screen Option or Command.
LOG OFF
CLOCK
AHU2 ALARM
OVERRIDE
1STFLOOR
AHU4
2NDFLOOR
PAGEDOWN
AHU5
Page 1
SYSTEMID
