Overriding Analog
Objects
System ID
Object ID
34 Network Terminal User's Manual
To override an analog object:
1. Select the system, the object, and the OVERRIDE command.
2. Follow the instructions at the top of the screen.
After you've entered the new OVERRIDE value, the NT displays the
current information for that object (including the new value).
Enter an OVERRIDE value. Press
ENTER after each choice.
Select EXECUTE, then ENTER.
AHU1
CHIR1SYS1
OVERRIDE VALUE ________
1 2
4
5
7
8
.
0
Figure 14: A Typical Analog Object Override Screen
Refer to Changing Schedules for information on scheduling an analog
object override.
LOG OFF
HOME
143.7 KTon
3
PREVIOUS
6
ERASE
9 EXECUTE
+ -
/
aoscrn
Current Value
Your New Entry
