Overriding Binary
Output Objects
To override a binary output object:
1. Select the system, the object, and the OVERRIDE command.
Note: Binary output objects mapped to locally controlled outputs
cannot be overridden.
2. Follow the instructions at the top of the screen.
After you've entered the new OVERRIDE state, the NT displays the
current information for that object (including the new state).
Select an available OVERRIDE
option, then press ENTER.
System ID
Object ID
Current
Override
Status
EMGNCY
Figure 13: A Typical Binary Object Override Screen
Refer to Changing Schedules for information on scheduling a binary
object override.
CHILLER5
CHL24 EMGNCY
NOMODE
Network Terminal User's Manual 33
