8. Options and Accessories
8.1.6. Analog inputs - Terminal X30/11, 12:
Analog input:
Number of analog inputs
Terminal number
Modes
Voltage level
Input impedance
Max. voltage
Resolution for analog inputs
Accuracy of analog inputs
Bandwidth
8.1.7. Digital outputs - Terminal X30/6, 7:
Digital output:
Number of digital outputs
Terminal number
Voltage level at digital/frequency output
Max. output current
Max. load
Max. capacitive load
8 Minimum output frequency
Maximum output frequency
Accuracy of frequency output
8.1.8. Analog output - Terminal X30/8:
Analog output:
Number of analog outputs
Terminal number
Current range at analog output
Max. load GND - analog output
Accuracy on analog output
Resolution on analog output

8.1.9. Encoder Option MCB 102

The encoder module can be used as feedback source for closed loop Flux control (par. 1-02) as
well as closed loop speed control (par. 7-00). Configure encoder option in parameter group 17-
xx
Used for:
• VVC
• Flux Vector Speed control
• Flux Vector Torque control
• Permanent magnet motor
Supported encoder types:
Incremental encoder: 5 V TTL type, RS422, max. frequency: 410 kHz
Incremental encoder: 1Vpp, sine-cosine
Hiperface® Encoder: Absolute and Sine-Cosine (Stegmann/SICK)
EnDat encoder: Absolute and Sine-Cosine (Heidenhain) Supports version 2.1
SSI encoder: Absolute
Encoder monitor:
136
plus
closed loop
MG.33.B9.02 - VLT
Max. error 0.5% of full scale
FC 301: 20 Hz/ FC 302: 100 Hz
Max. error: 0.1 % of full scale
Max. error: 0.5 % of full scale
® is a registered Danfoss trademark
FC 300 Design Guide
2
X30.11, X30.12
Voltage
0 - 10 V
> 10 kΩ
20 V
10 bit (+ sign)
2
X30.6, X30.7
0 - 24 V
40 mA
≥ 600 Ω
< 10 nF
0 Hz
≤ 32 kHz
1
X30.8
0 - 20 mA
500 Ω
12 bit
