FC 300 Design Guide
You can start and stop the connected motor
by means of LCP and the digital inputs.
Functions are divided into two groups.
Functions in group 1 have higher priority than
functions in group 2.
Motor:
f
JOG
The motor frequency when the jog function is activated (via digital terminals).
f
M
The motor frequency.
f
MAX
The maximum motor frequency.
f
MIN
The minimum motor frequency.
f
M,N
The rated motor frequency (nameplate data).
I
M
The motor current.
I
M,N
The rated motor current (nameplate data).
M-TYPE
Size and type of the connected motor (dependencies).
n
M,N
The rated motor speed (nameplate data).
P
M,N
The rated motor power (nameplate data).
T
M,N
The rated torque (motor).
U
M
The instantaneous motor voltage.
U
M,N
The rated motor voltage (nameplate data).
Break-away torque
MG.33.B9.02 - VLT ® is a registered Danfoss trademark
1. How to Read this Design Guide
Group 1 Reset, Coasting stop, Reset
and Coasting stop, Quick-stop,
DC braking, Stop and the "Off"
key.
Group 2 Start, Pulse start, Reversing,
Start reversing, Jog and
Freeze output
