Johnson Controls FRICK QUANTUM HD Setup page 9

Switch.
Refer to the following pictorial to construct a
crossover cable:
1 2 3 4 5 6
Left (Not
Crossed)
tions - Ethernet.
Component
Cable
Un-shielded solid 4-pair** (1000 Ft)
Crimp Tool
RJ-45 For Shielded 4-pair solid wire cable
Connectors
RJ-45 For Un-shielded 4-pair solid wire cable
Ethernet Cable Tester – Continuity only
Cable Tester
Complete Cable I/O Qualification Tester
Switches 7 RJ-45 Port and 1 ST Fiber Optic Port
* STP = Shielded Twisted Pair
QUANTUM™ HD COMPRESSOR CONTROL PANEL
7 8 3 6 1 4 5 2 7 8
Right (Crossed)
ETHERNET COMPONENT RECOMMENDATIONS
Description
Shielded solid 4-pair* (1000 Ft)
Shielded solid 4-pair*
Un-shielded solid 4-pair**
RJ-45 Crimp tool
5 RJ-45 port
8 RJ-45 port
COMMUNICATIONS SETUP
1 – White w/orange stripe
2 – Orange w/white stripe
3 – White w/green stripe
4 – Blue w/white stripe
Because of the large number of possible configurations
in an Ethernet network, you most likely will not have any
type of automated installation software. This means that
you will need to manually configure all the options. To
configure these options for the Quantum™ HD, please re-
fer to the next page in this manual entitled Communica-
Part Number
BOXCAT5E-DSSO
E-PLG-SOLID-SH
CR45-100S
9504 CS
9504 F
E-PLG-SOLID
345U5-1000BLK
0-5EPCS-BK
HT-210C
P-15027
S2307692
10-RJ1145
P-15007
5-554169-3
1-5E45-010
P-15029
TST-5150
TS075A-R2
N/A
SFN-5TX
SFN-7TX/FX ST
SFN-8TX
Both Ends of a crossover-cable
CAT-5 Ethernet cable color codes
5 – White w/blue stripe
6 – Green w/white stripe
7 – White w/brown stripe
8 – Brown w/white stripe
Manufacturer
Cablesforless.com
Cables Direct
Alpha Wire Co.
Ram Electronics
Computercablestore.com
Cablesforless.com
Stonewall Cable, Inc.
Computers4sure.com
Computercablestore.com
Stonewall Cable, Inc.
Tyco Electronics
Computercablestore.com
Stonewall Cable, Inc.
Cablesforless.com
Black Box
Fluke
Phoenix
090.040-CS (JAN 14)
Page 9
