Johnson Controls FRICK QUANTUM HD Setup page 91

Frick AB Modbus
®
Address Address Address
8311 N113:11 48312
8312 N113:12 48313
8313 N113:13 48314
8314 N113:14 48315
8315 N113:15 48316
8316 N113:16 48317
8317 N113:17 48318
8318 N113:18 48319
8319 N113:19 48320
8320 N113:20 48321
8321 N113:21 48322
8322 N113:22 48323
8323 N113:23 48324
8324 N113:24 48325
8325 N113:25 48326
8326 N113:26 48327
8327 N113:27 48328
8328 N113:28 48329
8329 N113:29 48330
8330 N113:30 48331
8331 N113:31 48332
8332 N113:32 48333
8333 N113:33 48334
8334 N113:34 48335
8335 N113:35 48336
8336 N113:36 48337
8337 N113:37 48338
8338 N113:38 48339
8339 N113:39 48340
8340 N113:40 48341
8341 N113:41 48342
8342 N113:42 48343
8343 N113:43 48344
8344 N113:44 48345
8345 N113:45 48346
8346 N113:46 48347
8347 N113:47 48348
8348 N113:48 48349
8349 N113:49 48350
8350 N113:50 48351
8351 N113:51 48352
8352 N113:52 48353
8353 N113:53 48354
QUANTUM™ HD COMPRESSOR CONTROL PANEL
COMMUNICATIONS SETUP
SETPOINT VALUES (Continued):
Read/
Write
R/W Sequencing - System 1 Compressor 4 Start #
R/W Sequencing - System 1 Compressor 5 Start #
R/W Sequencing - System 1 Compressor 6 Start #
R/W Sequencing - System 1 Compressor 7 Start #
R/W Sequencing - System 1 Compressor 8 Start #
R/W Sequencing - System 1 Capacity Control Setpoint
R/W Sequencing - System 1 Control Point
R/W Sequencing - System 1 Minimum Run Time
R/W Sequencing - System 1 Compressor 1 Capacity
R/W Sequencing - System 1 Compressor 2 Capacity
R/W Sequencing - System 1 Compressor 3 Capacity
R/W Sequencing - System 1 Compressor 4 Capacity
R/W Sequencing - System 1 Compressor 5 Capacity
R/W Sequencing - System 1 Compressor 6 Capacity
R/W Sequencing - System 1 Compressor 7 Capacity
R/W Sequencing - System 1 Compressor 8 Capacity
R/W Sequencing - System 1 Compressor 1 Run Time
R/W Sequencing - System 1 Compressor 2 Run Time
R/W Sequencing - System 1 Compressor 3 Run Time
R/W Sequencing - System 1 Compressor 4 Run Time
R/W Sequencing - System 1 Compressor 5 Run Time
R/W Sequencing - System 1 Compressor 6 Run Time
R/W Sequencing - System 1 Compressor 7 Run Time
R/W Sequencing - System 1 Compressor 8 Run Time
R/W Sequencing - System 1 Compressor 1 Minimum Capacity
R/W Sequencing - System 1 Compressor 2 Minimum Capacity
R/W Sequencing - System 1 Compressor 3 Minimum Capacity
R/W Sequencing - System 1 Compressor 4 Minimum Capacity
R/W Sequencing - System 1 Compressor 5 Minimum Capacity
R/W Sequencing - System 1 Compressor 6 Minimum Capacity
R/W Sequencing - System 1 Compressor 7 Minimum Capacity
R/W Sequencing - System 1 Compressor 8 Minimum Capacity
R/W Sequencing - System 1 Compressor 1 Follower Command
R/W Sequencing - System 1 Compressor 2 Follower Command
R/W Sequencing - System 1 Compressor 3 Follower Command
R/W Sequencing - System 1 Compressor 4 Follower Command
R/W Sequencing - System 1 Compressor 5 Follower Command
R/W Sequencing - System 1 Compressor 6 Follower Command
R/W Sequencing - System 1 Compressor 7 Follower Command
R/W Sequencing - System 1 Compressor 8 Follower Command
R/W Sequencing - System 1 Compressor 1 Start Inhibits
R/W Sequencing - System 1 Compressor 2 Start Inhibits
R/W Sequencing - System 1 Compressor 3 Start Inhibits
Description of Data
090.040-CS (JAN 14)
Page 91
Units
None
Temperature
Minutes
Real
Real
Integer
Percent (%)
None
