Johnson Controls FRICK QUANTUM HD Setup page 28

090.040-CS (JAN 14)
Page 28
RETURN OPERATING STATUS –
Page 1 Data:
Command structure:
Command Description
$ Start of command sequence.
ID Compressor (ID) code (01, 14, etc.)
Operating Status (D)ata –
D1
Page (1) command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Character
Description of returned data
Position
1 (A)cknowledge
2, 3 (ID) code verified
4-12 Suction Pressure
13-21 Suction Temperature
22-30 Discharge Pressure
31-39 Discharge Temperature
40-49 Oil Pressure
49-57 Oil Temperature
58-66 Filter Differential
67-75 Motor Current
76-84 FLA%
85-93 Kilowatts
94-102 Slide Valve
103-111 Slide Stop
112-120 Process Temperature
Checksum, Carriage Return, Line Feed if
121, 122
successful
QUANTUM™ HD COMPRESSOR CONTROL PANEL
COMMUNICATIONS SETUP
$IDD1
RETURN OPERATING STATUS –
Page 2 Data:
Command structure:
Command Description
$ Start of command sequence.
ID Compressor (ID) code (01, 14, etc.)
Operating Status (D)ata –
D2
Page (2) command.
CS Checksum
CR Carriage Return
RETURNED ANSWER,
Character
Description of returned data
Position
1 (A)cknowledge
2, 3 (ID) code verified
4-12 Alarm Status
13-21 Shutdown Status
22-30 Running Status
31-39 Slide Valve Load
40-49 Slide Valve Unload
49-57 Slide Stop Increase
58-66 Slide Stop Decrease
67-75 Stop Load/Force Unload Code
76-84 Separator Temperature
85-93 Balance Piston Pressure
94-102 Process Variable
103-111 Compressor Mode
Checksum, Carriage Return, Line Feed if
112, 113
successful
$IDD2
