Valor H6 Installation Manual

Direct vent zero clearance gas fireplace
Hide thumbs Also See for H6:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Manual
H6
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
▪
DANGER
4009064-01
Direct Vent Zero Clearance
Gas Fireplaces
natural gas
1400MN
propane gas 1400MP
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
Installer: Place model/serial number here.
Do not touch any electrical switch; do
▪
not use any phone in your building.
Leave the building immediately.
▪
Immediately call your gas supplier from
▪
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
▪
call the fi re department.
Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
